• Controls one door directly, with unlimited expansion capabilities.
  • TCP/IP communications (100/10Mbps).
  • DHCP or Static IP addresses.
  • Password protected built-in web server or FREE downloadable ‘Grid’ software.
  • Two Ethernet Ports allow for interfacing with additional IP devices like cameras additional door controllers, etc.
  • Live transaction monitoring.
  • Entry & exit reader capability.
  • Supports industry standard proximity, smart card, and multi-technology readers (Wiegand output).
  • Reader short circuit protection.
  • Compliant with PoE+ standard.
  • 60,000 users (up to 2 credentials per user).
  • Batch card enrollment.
  • 250 Time Zones and 1,000 User/ Door Groups.
  • Holiday support.
  • Scheduled Events.
  • Temporary Users.
  • Audit Trail – Up to 5,000 events from on-board storage, unlimited events with PLUS software (limited only by your alocated server space).
  • Status LED’s – Power, Communications, & Fault on-board diagnostic indicators Anti-tailgating.

For further details download the following datasheet:
